STANDARD EQUIPMENT GVWR 110,000# GAWR 25,000# Each (3 Axles)
FRAME & FEATURES: Capacity: 110,000# (55 Ton) Deck Rating: 70,000# In 10' Axles - 3-25,000 Lb. Dual Tire, Oil Bath Bearings; Prepped for Tire Inflation Suspension - Neway RLU228 Air Ride 22,500 Lb. Capacity Pin Setting - 21" Loaded Ground Clearance - 14" at Bottom of Gooseneck Loaded Deck Height - 37" Lights - Grote MicroNova® LED Clear Lens; Enhanced Stop, Turn, Tail and Tail; Rear Amber Strobe (10 Year Warranty) Tie Downs - Double Keyhole Chain Slots with Square Stake Pockets on 16" Centers Load Angle - 6.5 Degree BASE OPTIONS:
Toolboxes - Non-Load Bearing Top Opening Toolboxes Deck Width - 8' 6" Wide Deck Trailer Length - 53' Swing Clearance - 83.5" PARKING STANDS:
Parking Stands - Jost 2 Speed
WINCH & ACCESSORIES: Winch - 20K Braden, Planetary, 2 Speed w/Air Release/Spring Tension Upper Deck Slope Wear Protection - Slope Roller Wireless Remote Control (6 Function: Tilt, Travel, and Winch) DECK & ACCESSORIES:
Folding Steps - Both Street and Curb Side (Galvanized) Deck Type - 1-3/8" Apitong Wood Decking
SUSPENSION: Air Dump Valve Shock Straps, Wire Rope
TIRES & WHEELS: Tires - 235/75R 17.5 Double Coin Outside Wheel Type - 17.5 Dura-Brite Aluminum Wheel (8 Bolt) Inside Wheel Type - 17.5 Steel Hub Wheel (8 Bolt) Tire Air System - PSI Air Inflation System PAINT & SPECIAL OPTIONS:
Standard Landoll Branded Decals (Affects Lower Deck Only) Hot Dip Galvanizing Hot Dip Galvanized Under Carriage Weldment Hot Dip Galvanized Bumper Paint Over Galvanizing (Side Frame Web Only) Wet Paint Color - Black |
