Winches
Zip’s AW Direct stocks a variety of high-quality winches you can count on to provide the pulling power you need for any rigging, lifting and recovery situation. Rely on such trusted manufacturers as Warn, Ramsey and Mile Marker to supply the right winches for your ATVs and off-road vehicles. Truck and trailer winches and industrial winches for cranes and wreckers are also available here. Gear options include hydraulic worm and planetary drives with manual clutch, air clutch and remote clutch. Choose from short drum, long drum and standard drum with A-Rotation, B-Rotation, Clockwise and Counterclockwise motion. Manual cable hoists, hand winches and come-along winches can also be found online at Zip's AW Direct.
Refine Your Search
- Brand
-
-
-
-
-
-
-
-
- Gear Type
-
-
- Volt
-
-
- Winch Application
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
- Line Pull
-
-
-
-
-
-
-
-
-
-
-
-
Ramsey HD234 8,000 lb. Hydraulic Worm Winch w/ Ram-Lok - Jerr-Dan w/ Adapter Rod and Box Frame
Ramsey Omega 8,000 Heavy Duty Planetary Winch
Product Highlights
Automatic Load-Holding Brake
Equipped with a strong, automatic load-holding brake engineered for maximum strength and reliability. It securely holds the winch's full 8,000-lb. rated line capacity during stationary holds and heavy pulls.
Superior Cable Management
Includes an integrated Ramsey spring-loaded roller tensioner that maintains consistent tension on the drum. This prevents wire rope binding, reduces overlapping and significantly extends cable service life.
Low-Profile Envelope for Rollbacks & Car Carriers
Delivers an optimal power-to-weight ratio in a low-profile envelope designed to save space and weight. Its compact footprint allows for clean, easy installation in tight car carrier and rollback mounting setups.
Field-Serviceable Hydraulic Design
Engineered to eliminate job-site downtime, the Ramsey Omega 8 features a streamlined design that can be serviced directly in the field. This field-first construction saves maintenance hours and keeps recovery vehicles on the road.
Dual Free-Spool Clutch Control Options (Air Shift or Manual)
Available with a pneumatic air shift clutch for convenient cab-controlled free-spool actuation or a spring-loaded pull-and-rotate manual shift knob. Both options deliver rapid cable payout for fast, safe roadside setups.
High-Efficiency Planetary Gearing
Combines a rugged 5.1:1 single-stage planetary gear set with a heavy-duty 15.2 cu in./rev. hydraulic motor to deliver line retrieval speeds up to 52 FPM at 17 GPM (1st layer). Engineered for high mechanical efficiency, rapid line recovery and long service life under continuous usage.
Specifications
Manual
Simple, zero pneumatic lines required, ideal for straightforward mechanical beds.
Air Release
Integrates with existing onboard air systems, enables remote/cab operation and keeps drivers off the side of dangerous highways.
Dimensions
- Length: 26.99"
- Drum Diameter: 9.75"
- Height: 12"
Performance Specifications
- Rated Line Pull: 8,000 lbs.
- Weight (without cable): 126 lbs.
- Gear Reduction: 5.1:1
- Motor Size: 15.2 cu in./rev.
General Specs
- Compliance: Meets SAE J706 Standards
- Origin: Made in the USA
- Warranty: 2-Year Limited Manufacturer Warranty
Replacement Parts
When replacing a Ramsey Sierra winch with an Omega winch on car carrier beds, specific fluid tubes and bolt modifications are required.
Mounting Hardware
1/4" shorter bolts are required on the freewheel side of the mount when replacing a Sierra winch, #12-04008448.
FAQ
Q: What is the rated capacity of the Ramsey Omega winch?
A: The Ramsey Omega winch features a rated line pull capacity of 8,000 lbs., making it highly effective for car carriers, rollbacks and recovery setups.
Q: Does the Ramsey Omega 8K winch feature an automatic brake?
A: Yes, it is equipped with a strong, automatic load-holding brake engineered to securely hold the winch's full 8,000-lb. capacity during stationary holds and heavy pulls.
Q: What clutch control options are available on this winch?
A: The Ramsey Omega 8K is available with two clutch options: a pneumatic air shift clutch for convenient cab-controlled actuation or a spring-loaded pull-and-rotate manual shift knob.
Q: Is the Ramsey Omega 8K winch field-serviceable?
A: Yes. It is designed with a streamlined, field-first construction that allows maintenance and repairs to be done on the jobsite, keeping your recovery vehicle on the road.
Zip's Sierra Winch - Worm Gear Replacement Kit
Ramsey Winch 8,000-Lb. Hydraulic Industrial-Grade Winch, Series H246Y, Clockwise Rotation
WARN G2 Series 12 Hydraulic Industrial Winch
Mile Marker 12,000 lb Waterproof Electric Winch
Ramsey QM9000 9,000 lb. 12V Electric Planetary Winch
Anymount Swivel Winch
Ramsey HD234 with Adapter Rod
The Ramsey HD234 8,000 lb. Hydraulic Worm Winch with Adapter Rod is built specifically for operators needing a direct core replacement on Jerr-Dan rollback carriers and car haulers. Designed to re-use your carrier’s existing operational mounting frame, this heavy-duty 8K winch comes pre-fitted with the specialized Jerr-Dan adapter rod extension for direct linkage to factory manual clutch controls.
Product Highlights
8,000 lbs. Rated Line Pull
Built to handle heavy passenger cars, SUVs and commercial equipment, giving rollback operators full pulling authority across standard 10-series and 12-series carrier duties.
Self-Locking Mechanical Security
Features Ramsey’s precision-machined worm gear drive that automatically locks the drum in place the moment hydraulic pressure stops, preventing accidental freespooling under heavy tension.
Ram-Lok® Spring-Loaded Manual Clutch
Features Ramsey’s proven pull-and-rotate Ram-Lok® mechanism, giving operators smooth, instant drum disengagement for fast free-spooling wire rope payout.
Fast Line Recovery Speed
Engineered for optimum hydraulic efficiency, retrieving line at up to 28 feet per minute (at 15 GPM) to speed up hookups and reduce hazardous dwell time on highway shoulders.
Integrated Jerr-Dan Adapter Rod Assembly
Comes factory-equipped with the extending adapter rod required to interface directly with standard Jerr-Dan manual clutch linkages, eliminating custom shop fabrication.
Cost-Effective Drop-In Assembly
Keeps repair costs low by allowing you to replace a worn or damaged winch core while keeping your intact Jerr-Dan subframe box structure.
Specifications
- Rated Line Pull: 8,000 lbs. (3,628 kg) — 1st Layer
- Gear Reduction Ratio: 34:1 Worm Gear
- Line Speed (1st Layer): 28 FT/MIN @ 15 GPM
- Hydraulic Requirement: 2,375 PSI @ 15 GPM
- Motor Displacement: 3.6 cu. in./rev.
- Clutch Type & Control: Ram-Lok® Manual Pull-and-Rotate
- Recommended Wire Rope: 3/8" (Up to 140' Drum Capacity)
- Weight (Without Cable): 110 lbs.
- Included Hardware: Jerr-Dan Adapter Rod (Box Frame Not Included)
Dimensions & Drum Spec
- Drum Barrel Diameter: 3.5"
- Drum Flange Diameter: 7.25"
- Drum Length: 11.31"
- Cable Capacity: 140 ft. of 3/8" wire rope
Equipment Compatibility
Direct core replacement for Jerr-Dan 10-Series and 12-Series rollback carriers equipped with factory manual clutch controls and an intact, undamaged mounting box structure.
To note: If your mounting structure is damaged or missing, order Zip's Part #121795 for the complete assembly with box frame.
FAQ
Q: What is the rated capacity of the Ramsey HD234 winch?
A: The Ramsey HD234 hydraulic worm winch features an 8,000 lb. (3,628 kg) rated line pull on the first layer, giving rollback operators plenty of pulling authority for heavy passenger cars, SUVs and commercial equipment.
Q: Is this winch a direct replacement for Jerr-Dan rollback carriers?
A: This specific Ramsey HD234 is designed as a direct core replacement for Jerr-Dan 10-series and 12-series rollback carriers. It includes the integrated adapter rod required to interface directly with standard Jerr-Dan manual clutch linkages.
Q: How does the Ram-Lok clutch mechanism work?
A: The winch utilizes Ramsey’s proven pull-and-rotate Ram-Lok® spring-loaded manual clutch. This allows operators to achieve smooth and instant drum disengagement for fast, free-spooling wire rope payout.
Q: How fast is the line recovery speed on the Ramsey HD234?
A: When supplied with the required 15 GPM of hydraulic flow, the Ramsey HD234 retrieves line at up to 28 feet per minute on the first layer, helping to speed up hookups and reduce dwell time on the road.
Q: Does the Ramsey HD234 have a brake system?
A: Yes, it features self-locking mechanical security. The precision-machined worm gear drive automatically locks the drum in place the moment hydraulic pressure stops, preventing accidental freespooling under tension.
Warn 12 Series 12,000 lb. Anti-Clockwise Hydraulic Planetary Winch - Gen 2
Warn 15 Series Counter Clockwise "B" Rotation Hydraulic Planetary Winch
Ramsey Patriot 15000 Electric Planetary Winch
Ramsey 8,000 lb. Planetary Winch w/ Counter Clockwise "B" Rotation
Ramsey DC200 8,000 lb. Industrial Electric Worm Winch
Warn 20XL Series 20,000 lb. Hydraulic Planetary Winch w/ Air Clutch
Ramsey QM9500 9,500 lb. Planetary Winch
Ramsey Patriot Profile 12000 Electric Planetary Winch w/ Wireless Remote
Ramsey RE 12000 RX Winch
Warn Winch 12k Complete Assembly
Warn XD9 Winch
Ramsey Patriot 6000 Electric Planetary Winch
Ramsey REP 8000 Electric Planetary Winch
Mile Marker 9,000 lb. Hydraulic Planetary Winch
Ramsey Commercial-Grade 9500 Patriot 9,500 lb. 12V Electric Planetary Winch
Ramsey Patriot 9500 Electric Planetary Winch
Ramsey QM8000 8,000 lb. 12V Electric Planetary Winch
Ramsey Winch 8,000-Lb. Hydraulic Industrial-Grade Winch, Series H246, Clockwise Rotation
Ramsey RE 12000R 12,000 lb. Electric Planetary Winch
DP 12k Worm Winch w/ Manual Free Spool
Zip's Sierra Winch - Worm Gear Replacement Kit
Warn 12 Series 12,000 lb. 24V Electric Planetary Winch
Warn Industries VR EVO 10 Winch
Mile Marker SEC12 12,000 lb Waterproof 24V Electric Winch
Mile Marker Rhino Pull 1000 Portable Electric Winch
Mile Marker Rhino Pull 1000 Replacement Battery
Warn 20XL Series 20,000 lb. Hydraulic Planetary Winch w/ Manual Clutch
Warn PullzAll 1,000 lb. Rechargable Cordless Portable Winch
Mile Marker 15,000 lb Waterproof Electric Winch
Miller Replacement 12,000 lbs Ramsey Winch
Ramsey REP 8.5E 8,500 lb. Electric Planetary Winch
Ramsey Patriot Profile 6000R 6,000 lb. Electric Planetary Winch
Ramsey REP 5000 Electric Planetary Winch
Ramsey Patriot Profile 8000R 8,000 lb. Electric Planetary Winch
Ramsey Patriot 8000 Electric Planetary Winch
Ramsey REP 9000 Electric Planetary Winch
Ramsey Patriot Profile 9000 R 12V Winch
Zacklift 20,000 lb. Warn Planetary Winch
Zacklift 20,000 lb. Warn Planetary Winch
Ramsey RE 8000R 8,000 lb. Electric Worm Gear Winch w/ 12' Wire Pendant
Ramsey HD-234R 8,000 lb. Hydraulic Worm Winch w/ Ram-Lok - Jerr-Dan
Ramsey 9,000 lb. Industrial-Grade Electric Worm Winch
Ramsey DC-300 9,000 lb. Industrial Electric Worm Winch
Ramsey Triple-X 6000 12V Electric Planetary Winch
Ramsey 9,000 lb. Industrial-Grade Electric Worm Winch
Zacklift 30,000 lb. Warn Planetary Winch
Winches for Every Application
Winches are essential tools for towing, recovery, industrial work, and trailer operations. Whether you’re outfitting a tow truck, flatbed, trailer, or off-road vehicle, having the right winch ensures safe and reliable pulling power. At Zip’s, we carry a wide range of winches for sale from trusted brands like Ramsey Winch, Warn Industries, and Mile Marker, with models suited for trucks, trailers, and industrial applications.
Why Choose a Winch
A truck winch or tow truck winch is more than just a pulling device—it’s a vital piece of equipment that provides safety, control, and efficiency. Choosing the right winch for your application depends on several factors:
- Pulling Capacity: Winches are available in capacities ranging from 8,000 lbs to over 30,000 lbs, making them suitable for light-duty trailers all the way to heavy-duty industrial recovery.
- Gear Types: Both planetary and worm gear winches are available, with planetary designs offering faster line speeds and worm gears delivering greater control under load.
- Applications: Flatbed operators often rely on flatbed winches for secure loading, while industrial users may need high-capacity winches for construction, mining, or utility work.
- Power Source: Winches are powered manually, electrically, or hydraulically, giving you flexibility depending on your equipment setup.
Types of Winches Available
We stock a complete range of winches to meet different professional and recreational needs:
- Hydraulic Winches – Best suited for heavy-duty towing and industrial recovery work.
- Electric Winches – Versatile and widely used for trucks, trailers, and off-road vehicles.
- Manual Winches – Simple and reliable, ideal for lighter loads and portable use.
Each type has unique advantages, and you’ll find them organized into sub-categories for easier selection.
Trusted Winch Brands
Quality matters when it comes to safety and performance. That’s why we carry top brands known for their innovation and reliability:
- Ramsey Winch – Industry leader in hydraulic and industrial winches.
- Warn Industries – Known for rugged winches trusted in recovery and off-road applications.
- Mile Marker – Affordable and dependable winches designed for both trucks and trailers.
Winch Parts and Accessories
To keep your winch in peak condition, explore our full selection of winch parts. From replacement cables and hooks to mounting hardware and lubricants, we stock everything needed to maintain safe and reliable performance.
Helpful Resources
Not sure which winch is right for your truck or trailer? Our blog covers everything from sizing to maintenance:
FAQ: Winches
What size winch do I need for my truck or trailer?
A good rule of thumb is to choose a winch rated for at least 1.5 times the weight of the vehicle or load you’ll be pulling.
What’s the difference between planetary and worm gear winches?
Planetary gear winches offer faster line speeds and compact designs, while worm gear winches provide smoother control and better load holding.
Can I use the same winch for towing and industrial applications?
Many heavy-duty winches are versatile, but always match the winch’s line pull and design to your specific application for safety.
How do I maintain my winch?
Regular inspection, lubrication, and proper cable care extend the life of your winch. Refer to our How to Maintain Your Winch guide for best practices.
Do you carry winches for trailers?
Yes, we stock a range of trailer winches designed for secure loading and transport, including options for flatbeds and enclosed trailers.
