Dica Safety Tech Super Duty Round Outrigger Pads

Dica Safety Tech Outrigger Pads are engineered from top to bottom and built using propietary engineered thermoplastic formula for improved performance that meets your everday needs.

Owners and operators love Dica Safety Tech Pads for the toughness, durability, and ease of use. These qualities help teams work safely, effiently and cost-effectively in some of the toughest environments around the world.

• Engineered Thermoplastic Material
• Tuff Grip Handles
• Waterproof and Chemical Resistant
• Industrial Grade Safety Texturing
• Radius Edges and Corners
• Non-Conductive
• Lifting Points for Rigging
• Guaranteed Unbreakable
• Max Allowable Pressure (Crush Rating): 600 - 750psi
• Working Load Limit: 130,000 - 240,000 lbs
• Sold as Each

  Best Applications:
• Mobile Cranes
• Concrete Pumpers
• Aerial Lifts
• Rock Crushers



  Item #	Size	Pad Thickness	Approximate Area	Weight	Crush Rating	Working Load Limit
  DR36-3	36" x 3"	3"	7 Sq. Ft.	102 lbs.	600 psi	130,000 lbs.
  DR42-3	42" x 3"	3"	9.5 Sq. Ft.	138 lbs.	600 psi	150,000 lbs.
  DR48-3	48" x 3"	3"	12.5 Sq. Ft.	180 lbs.	600 psi	170,000 lbs.
  DR60-3	60" x 3"	3"	19.5 Sq. Ft.	285 lbs.	600 psi	210,000 lbs.
