Fiamm Heavy-Duty Air Horn and Compressor Kit

Leave a Review

Shop all Fiamm Technologies LLC products

Picture of Fiamm Heavy-Duty Air Horn and Compressor Kit

SKU: AH10

Price: $101.99

Qty:

Go Straight to Checkout

Qualifies for Free Shipping
with $199.00 minimum order

Description

This is a heavy duty air horn and compressor kit from Fiamm Industries. The twin air horn is the result of a unique sound chamber design which provides increased sound intensity from low pressure air sources. The sleek self-mount styling features dual stainless steel projectors and an anodized aluminum motor housing.

Sound Pressure Level: 117 (2m) dB(A)
Frequency L : 260 Hz
Frequency H : 300 Hz
Working Pressure: 500 - 1200 kPa
Air Consumption: 0,9 l/sec
Operating Temperature: -30? to +80? ?C
Storage Temperature: -30? to +80? ?C
Corrosion Resistance: > 600 (salt spray test) Hours
Operating Relative Humidity: 30 to 80 %
Durability (1 sec ON, 4 sec OFF): >50 000 Cycles
Continuous Blowing: 60 min
Vibration (30 min, 3 axis): 1 g
Weight: 900 gr
Main Materials: Stainless Steel, Aluminum
Main Applications: Trucks

Documents

AH10 Product Specs

Shipping & Returns

Expedited orders must be placed by 12 p.m. CST. Items under 110 lbs ship via standard parcel (UPS Ground). Items 110–150 lbs may ship via ground or truck freight depending on size and destination.
Larger or heavier items ship via truck freight, which may require additional delivery time.

Please inspect all shipments within 10 days of delivery. Return requests must be submitted within 45 days.

For full details, view our Shipping & Returns Policy.

Learn More

Product Information

Item #	MFG #
AH10	6233022
