Phoenix USA replacement Jam Nut for QH1300AS

Trim-Lok's edge trim is flexible Poly Vinyl Chloride (PVC) trim with individual internal metal clips and gripping tongue to provide a stronger grip. As you likely already know, having the right rubber trim for metal edges can make an impact on any project. Whether you run an auto repair shop and need sewable upholstery trim for cars and trucks or manufacture furniture for a living and require decorative trim for your line of products, Trim-Lok manufactures flexible edge trim that can be used in many different industries. As an added bonus, each flexible edging strip purchased from Trim-Lok is manufactured with individual internal metal clips and a gripping tongue. These clips and tongue provide a stronger grip, meaning Trim-Lok's line of edge trim products will last longer than many alternatives available on the market. If you're looking for a flexible metal trim with strong gripping power, excellent resistance to sunlight, water, and the ozone, and a strong, outer coating material, look no further- build your own edge trim today and see the difference for yourself.

The pros know that you don't mess around when it comes to brakes. FVP Brake Cleaner meets or exceeds OE quality with a price so competitive it will stop you in your tracks. FVP Non-Chlorinated Brake Part Cleaner removes oil, grease, brake fluid and containments quickly, with no residue.

Note: Special Handling Fees Apply for Specific Items

One of the most popular winches in the Towing & Recovery industry. These 8000 lb. Ramsey Winches are used on most Chevron and many other tow trucks and car carriers. These winches are just the basic winch with no hydraulic motor. This makes it more economical to replace your old winch rather than to repair it.

• Model: HD-234R
• Line Pull: 8,000 lbs
• Mounting Configuration: Front Overwind Right Side/Rear Overwind Left Side
• Gear Ratio: 34:1
• Motor Included: No
• Angles Included: No
• Drum Length: 11"+-/16"
• See Brochures for Product Drawings
• Adjustable/Automatic Brake: No
• Fast Line Speed
• Recommended cable 3/8
• Meets SAE-J706
• Made in the USA



  Applications

• Replaces Chevron Car Carrier OEM Winches
• Replaces Jerr-Dan Car Carrier OEM Winches
• General Industrial
• Mining & Construction
• Railroad
• Specialty Vehicle
• Towing & Recovery
• Towing & Recovery (Carrier)
• Towing & Recovery (Light Wrecker)
• Trailer



  Winch Mount Configuration





  Model Specifications

• Rated Line Pull: 8,000 lbs / 3,629 Kg (1st Layer of Cable)
• 1st Layer Line Speed: 28'/min / 8.5m/min
• Gear Ratio: 34:1
• Weight w/o Cable: 110 lbs / 50 Kg
• Brake: "Optional auxiliary brake is available", Yes - brake is self-locking (Includes auxiliary brake)
• Cable: None
• Drum Size (L x F x B): 11.31" x 7.25" x 3.50" / 287.3mm x 184.2mm x 88.9mm
• Cable Capacity: 140' / 42.7m
• Recommend Cable Size: 3/8" / 9.5mm
• Hydraulic Pressure Required: 2,375 PSI (164 Bar)
• Hydraulic Flow Required: 15.0 GPM (57 LPM)
• Motor Size: 3.6 Cu. In. (59 cc)
• Clutch Type: Blocked, RAM-LOK?, DOW-LOK?, Lever Style
• Clutch Control: Air, Manual, Electric



  HD-234R Specifications:

• Ramsey Part Number: 121807
• Model: HD-234R
• Line Pull: 8,000 lbs
• Clutch: Ram-Lok
• Mounting Configuration: Front Overwind Right Side/Rear Overwind Left Side
• Gear Ratio: 34:1
• Motor Included: No
• Angles Included: No
• Drum Length: 11"+-/16"
• Adjustable/Automatic Brake: No
• Fast Line Speed
• Recommended cable 3/8
• Meets SAE-J706
• Made in the USA



  HD-200R Specifications:

• Ramsey Part Number: 121818
• Model: HD-234R
• Line Pull: 8,000 lbs
• Clutch: Lever
• Mounting Configuration: Front Right Overwind Side/Rear Overwind Left Side
• Gear Ratio: 34:1
• Motor Included: No
• Angles Included: No
• Drum Length: 11"+-/16"
• Adjustable/Automatic Brake: No
• Fast Line Speed
• Recommended Cable: 3/8"
• Meets SAE-J706
• Made in the USA
• For an alternative winch see part number H-246
• Replaces part number 12-0300250



  HD-234RA Specifications:

• Ramsey Part Number: 121797
• Model: HD-234R
• Line Pull: 8,000 lbs
• Clutch: Air Shift
• Mounting Configuration: Front Overwind Right Side/Rear Overwind Left Side
• Gear Ratio: 34:1
• Motor Included: No
• Angles Included: No
• Drum Length: 11.125"+-/16"
• Adjustable/Automatic Brake: No
• Fast Line Speed
• Recommended Cable: 3/8"
• Meets SAE-J706
• Made in the USA

Note: Special Handling Fees Apply for Specific Items

Easily mount toolboxes on rollbacks or carriers. Used for 24" X 24" toolboxes on car carrier beds.

• 24"X24" or 24"X30"
• Pre drilled holes
• Sturdy steel angle iron
• Sold as each

  Available in the following sizes



  Item #	Size	Finish
  LR-2G	24" x 24"	Galvanized
  LR-5	24" x 24"	Powder Coated Black
  LR-5TG	24" X 30"	Tall Galvanized
  LR-5T	24" X 30"	Tall Powder Coated Black
