Part Number | Type | Dimensions (LxWxH) | Weight | Working Pressure | Air Requirement | Max Lift Capacity | Max Lift Height |
---|---|---|---|---|---|---|---|
77973 | SLK1 | 6" x 6" x 1" | 1.2 lbs | 116 psi | 0.2 cu. ft. | 1.2 US Tons | 3.1" |
77974 | SLK3 | 9" x 9" x 1" | 3 lbs | 116 psi | 0.5 cu. ft. | 3 US Tons | 5.1" |
77975 | SLK6 | 12" x 12" x 1" | 4 lbs | 116 psi | 1.5 cu. ft. | 6.1 US Tons | 6.3" |
76734 | SLK10 | 15" x 15" x 1" | 8 lbs | 116 psi | 3 cu. ft. | 11.1 US Tons | 8.3" |
76735 | SLK14 | 18" x 18" x 1" | 11 lbs | 116 psi | 5.4 cu. ft. | 14.9 US Tons | 9.8" |
76736 | SLK21 | 22" x 22" x 1" | 15 lbs | 116 psi | 10.5 cu. ft. | 23.2 US Tons | 11.8" |
76737 | SLK25 | 24" x 24" x 1" | 20 lbs | 116 psi | 14.7 cu. ft. | 27.7 US Tons | 13.4" |
76738 | SLK33 | 27" x 27" x 1" | 24 lbs | 116 psi | 21.9 cu. ft. | 36.3 US Tons | 15" |
76739 | SLK45 | 31" x 31" x 1" | 31 lbs | 116 psi | 32.5 cu. ft. | 49.1 US Tons | 16.5" |
SAVA-76794 | SLK55 | 34" x 34" x 1" | 40 lbs | 116 psi | 46.1 cu. ft. | 60.5 US Tons | 18.5" |
SAVA-573241 | SLK70 | 37" x 37" x 1" | 50 lbs | 116 psi | 53.2 cu. ft. | 77.4 US Tons | 20.5" |
Part Number | Type | Dimensions (LxWxH) | Weight | Working Pressure | Air Requirement | Max Lift Capacity | Max Lift Height |
---|---|---|---|---|---|---|---|
77973 | SLK1 | 6" x 6" x 1" | 1.2 lbs | 116 psi | 0.2 cu. ft. | 1.2 US Tons | 3.1" |
77974 | SLK3 | 9" x 9" x 1" | 3 lbs | 116 psi | 0.5 cu. ft. | 3 US Tons | 5.1" |
77975 | SLK6 | 12" x 12" x 1" | 4 lbs | 116 psi | 1.5 cu. ft. | 6.1 US Tons | 6.3" |
76734 | SLK10 | 15" x 15" x 1" | 8 lbs | 116 psi | 3 cu. ft. | 11.1 US Tons | 8.3" |
76735 | SLK14 | 18" x 18" x 1" | 11 lbs | 116 psi | 5.4 cu. ft. | 14.9 US Tons | 9.8" |
76736 | SLK21 | 22" x 22" x 1" | 15 lbs | 116 psi | 10.5 cu. ft. | 23.2 US Tons | 11.8" |
76737 | SLK25 | 24" x 24" x 1" | 20 lbs | 116 psi | 14.7 cu. ft. | 27.7 US Tons | 13.4" |
76738 | SLK33 | 27" x 27" x 1" | 24 lbs | 116 psi | 21.9 cu. ft. | 36.3 US Tons | 15" |
76739 | SLK45 | 31" x 31" x 1" | 31 lbs | 116 psi | 32.5 cu. ft. | 49.1 US Tons | 16.5" |
SAVA-76794 | SLK55 | 34" x 34" x 1" | 40 lbs | 116 psi | 46.1 cu. ft. | 60.5 US Tons | 18.5" |
SAVA-573241 | SLK70 | 37" x 37" x 1" | 50 lbs | 116 psi | 53.2 cu. ft. | 77.4 US Tons | 20.5" |
Part Number | Type | Dimensions (LxWxH) | Weight | Working Pressure | Air Requirement | Max Lift Capacity | Max Lift Height |
---|---|---|---|---|---|---|---|
77973 | SLK1 | 6" x 6" x 1" | 1.2 lbs | 116 psi | 0.2 cu. ft. | 1.2 US Tons | 3.1" |
77974 | SLK3 | 9" x 9" x 1" | 3 lbs | 116 psi | 0.5 cu. ft. | 3 US Tons | 5.1" |
77975 | SLK6 | 12" x 12" x 1" | 4 lbs | 116 psi | 1.5 cu. ft. | 6.1 US Tons | 6.3" |
76734 | SLK10 | 15" x 15" x 1" | 8 lbs | 116 psi | 3 cu. ft. | 11.1 US Tons | 8.3" |
76735 | SLK14 | 18" x 18" x 1" | 11 lbs | 116 psi | 5.4 cu. ft. | 14.9 US Tons | 9.8" |
76736 | SLK21 | 22" x 22" x 1" | 15 lbs | 116 psi | 10.5 cu. ft. | 23.2 US Tons | 11.8" |
76737 | SLK25 | 24" x 24" x 1" | 20 lbs | 116 psi | 14.7 cu. ft. | 27.7 US Tons | 13.4" |
76738 | SLK33 | 27" x 27" x 1" | 24 lbs | 116 psi | 21.9 cu. ft. | 36.3 US Tons | 15" |
76739 | SLK45 | 31" x 31" x 1" | 31 lbs | 116 psi | 32.5 cu. ft. | 49.1 US Tons | 16.5" |
SAVA-76794 | SLK55 | 34" x 34" x 1" | 40 lbs | 116 psi | 46.1 cu. ft. | 60.5 US Tons | 18.5" |
SAVA-573241 | SLK70 | 37" x 37" x 1" | 50 lbs | 116 psi | 53.2 cu. ft. | 77.4 US Tons | 20.5" |
