Truck Inspection Checklist

CHP Inspection Checklist Header

Follow this checklist to help maintain your equipment and keep it in compliance with DOT inspection requirements. The checklist is tailored to tow companies for the California Highway Patrol inspection program but can also be used as a guide for general commercial vehicle and tow truck inspections. Most categories include links to the replacement parts if the original parts are found to be defective. Truck inspections make a difference, and whether you are prepping for the California Vehicle Code Inspection or your state’s annual vehicle inspection certification, this checklist is the first tool you need to reach for to ensure compliance for your fleet.

Download the CHP checklist PDF here:


California Vehicle Code Requirements.
      Current Registration   4000 CVC
    Headlights   24400 CVC
   Beam Indicator   24408 CVC
    Tail Lamps   24600 CVC   Shop Now
    License Plate Lamp  24601 CVC  Shop Now
    Stop Lamps   24603 CVC   Shop Now
    Extension Lights  24605 CVC   Shop Now
    Backup Lamps (1969+)   24606 CVC   Shop Now
   Reflectors, Rear  24607 CVC  Shop Now
   Reflectors, Front and Side (1968+)  24608 CVC  Shop Now
   Turn Signals  24951 CVC  Shop Now
   Clearance Lamps (>80" Wide)   25100 CVC  Shop Now
   Amber Warning Lights  25253 CVC  Shop Now
   Warning Devices (Reflectors)   25300 CVC  Shop Now
   Service Brakes  26311 CVC
      Parking Brake   26451 CVC   Shop Now
    Windshield   26700 CVC
   Windshield Wipers   26706 CVC
    Mirrors   26709 CVC   Shop Now
    Horn  27000 CVC  Shop Now
    Exhaust System   27150 CVC
    Fuel Cap  27155 CVC
    Tire Tread   27465 CVC
   Fenders/Mud Guards   27600 CVC  Shop Now
   Broom  27700 CVC  Shop Now
   Shovel  27700 CVC  Shop Now
   Fire Extinguisher
 4B, C Rating
 27700 CVC  Shop Now
   Safety Chains  29004 CVC  Shop Now
   Signs  27907 CVC  Shop Now


Service and other equipment.
   Flashlight  Shop Now
   Wrecking Bar (Large Pry Bar)  Shop Now
   Six (6) 30-Minute Flares or 6 Reflectorized
 Cones, Min. 12" Ht.
 Shop Now
      Trash Cans & Absorbent (4 Gallon
 Minimum)
 Trash Cans   Aborbents
    Shop Rags or Paper Towels   Shop Now
   Shop to Truck Communications (Cell
 Phones / 2-Way Radio)
    Approved Fuel Containers (Classes A and B)
 If Carried
 Shop Now
    Booster Battery or Hot Box  Shop Now
   Hydraulic Jack  Shop Now
      Tire Changing Equipment   Shop Now
    Rubber Mallet / Hub Cap Tool (Classes A and B)  Shop Now
   Lockout Tools (Classes A and B)   Shop Now
    Motorcycle Straps (Class A)   Shop Now
    Sledge Hammer (Classes B, C, and D)  Shop Now
    Tool Kit   Shop Now
   Reflective Safety Attire  Shop Now


Towing Equipment.
      Manufactured Rating Plates   Shop Now
    Controls Labeled   Shop Now
   Wrecker Boom Assembly
 Shop Now
    Wheel Lift Assembly
 Shop Now
    Body and Towing Equipment
 Mounting Bolts
    Winch Rating:   Boom Capacity:
      Wrecker Controls
 Shop Now
    Throttle Control (If Equipped)  Shop Now
   Hydraulic Rams, Hoses, Valves
    Cable Sheaves  Shop Now
    Recovery Chain  Shop Now


Wheel Lift.
      Pivot Pin   Shop Now
    Wheel Tie Down Safety Straps or Chains   Shop Now

      "L" Arms  Shop Now
   Claw


Conventional.
      Tow Sling Assembly (Check for bent inner tubes)   Shop Now
      Sling Pads   Shop Now


Car Carrier.
      Carrier Bed Frame   Shop Now
   Bed Hinges  Shop Now
   Loading Bridle   Shop Now
      Bed Safety Lock   Shop Now
   Loading Bridle  Shop Now


Tow Truck Equipment Specifications (By Class) Class A.
      Minimum 14,000 lbs. GVWR Chassis
   4-Ton Boom Rating
   One 4-Ton Snatch Block  Shop Now
   Tow Dolly (w/ Wheel Tie Down Straps)  Shop Now
   Steering Wheel Securement Device  Shop Now
   Tow Sling "Minimum" 3,000 lbs. (If Equipped)  Shop Now
   Tow Chains "Minimum"  5/16"Grade 70 w/
 J/T Hooks
 Shop Now
      Two (2) Safety Chains 5/16" Alloy or OEM
 Specifications
 Shop Now
   Wheel Lift Rating - 3,000 lbs. Extended
   Two (2) Crossbeams,  (1) 48"L x 4"W x 4"D and (1) 60"L x 4"W x 4"D
   100'L x 3/8" dia. Cable 6 x 19 Wire Rope
 or OEM Specifications
 Shop Steel  Shop Fiber


Class A Car Carrier One Vehicle.
      Minimum 19,000 lbs. GVWR Chassis
   50'L x 3/8" dia. Cable 6 x 19 Wire Rope
 or OEM Specifications
 Shop Steel  Shop Fiber
   Loading Bridle w/ J/T Hooks  Shop Now
      Four (4) Safety Chains 5/16" Grade 70 or Rated Nylon
 Straps w/ Ratchets
 Shop Now
   Adequate Crossbeams or Ramping Material


Class A Car Carrier Two Vehicle.
      Minimum 23,500 lbs. GVWR Chassis
   Loading Bridle w/ J/T Hooks  Shop Now
   50'L x 3/8" dia. Cable 6 x 19 Wire Rope
 or OEM Specifications
 Shop Steel  Shop Fiber
   Alloy/OEM Spec & Wheel Straps - Towed
 Vehicle

      Four (4) Safety Chains 5/16" Alloy
 or OEM Specs. & Two (2) for Towed Vehicle
 Shop Now
   Steering Wheel Securement Device  Shop Now
   Adequate Crossbeams or Ramping Material


Class B.
      Minimum 33,000 lbs. GVWR Chassis
   16-Ton Boom Rating
   150'L x 7/16" dia. Cable 6 x 19
 Wire Rope or OEM Specifications
Shop Steel Shop Fiber
   Safety Chains 1/2" Alloy or OEM
 Specifications
 Shop Now
   Two (2) 8-Ton Snatch Blocks  Shop Now
   Air Brakes or Hydraulic w/ Air
 Hookup Package
   Air Hoses and Fittings  Shop Now  Quick Connect Kit
   Steering Wheel Securement Device  Shop Now
   Axle Covers/Caps  Shop Now
      Tow Sling 7,000 lbs. Rating (If Equipped)
   Truck Hitch/Tow Bar with 7,000 Pound Rating (If Equipped)
   Two (2) 48"L x 6"W x 4"D Crossbeams (Minimum)
   Tow Chains "Minimum" 1/2" Grade 70 with JT Hooks  Shop Now
   Wheel Lift Rating — 10,000 lbs. Retracted
   Wheel Lift Rating — 8,000 lbs. Extended
   Under Lift/Fork Adapters w/ Tie-Down Straps or Chains  Shop Now
   Safety Tie-Down Chains and Binders  Shop Now
   Aluminum Tow Angles (Minimum 2)  Shop Now


Class B Car Carrier One Vehicle.
      Minimum 33,000 lbs. GVWR Chassis
   50'L x 3/8" dia. Cable 6 x 19 Wire Rope
 or OEM Specifications
 Shop Steel  Shop Fiber
   Loading Bridle w/ J/T Hooks   Shop Now
   Steering Wheel Securement Device   Shop Now
      Two (2) Safety Chains 5/16" Alloy/OEM Spec & Wheel Straps for
 Towed Vehicle
   Four (4) Safety Chains 5/16" Grade 70 or OEM
 Specifications
 Shop Now
   Adequate Cross Beams or Ramping Material


Class C.
      Minimum 52,000 lbs. GVWR Chassis
   25-Ton Boom Rating
   200'L x 5/8" dia. Cable 6 x 19 Wire
 Rope or OEM Specifications
 Shop Steel  Shop Fiber
   Two (2) Safety Chains 5/8" Alloy or
 OEM Specifications
 Shop Now
   Two (2) 12-Ton Snatch Blocks  Shop Now
   Air Brakes w/ Air Hookup Package
   Air Hoses and Fittings  Shop Now  Quick Connect Kit
   Steering Wheel Securement Device  Shop Now
   Axle Covers/Caps  Shop Now
   Truck Hitch/Tow Bar 12,000 lbs. Rating (If Equipped)
      Tow Chains 5/8" Grade 70 or OEM Specifications  Shop Now
   Two (2) 48"L x 6"W x 4"D Crossbeams (Minimum)
   Pintle Hook
   Under Lift Rating — 25,000 lbs. Retracted
   Under Lift Rating — 12,000 lbs. Extended
   Wheel Lift Safety Straps or Chains  Shop Now
   Under Lift/Fork Adapters w/ Tie-Down Chains and
 Binders
 Shop Now
   Aluminum Tow Angles (Minimum 2)  Shop Now
   Safety Tie-Down Chains and Binders  Shop Now
   Tow Sling 12,000 lbs. Rating (If Equipped)  Shop Now


Class D.
      Minimum 54,000 lbs. GVWR Chassis
   35-Ton Boom Rating
   250'L x 3/4" dia. Cable 6 x 19
 Wire Rope or OEM Specifications
 Shop Steel  Shop Fiber
   Two (2) Safety Chains 5/8" Alloy or
 OEM Specifications
 Shop Now
   Two (2) 12-Ton Snatch Blocks  Shop Now
   Air Brakes w/ Air Hookup Package
   Air Hoses and Fittings  Shop Now  Quick Connect Kit
   Steering Wheel Securement Device  Shop Now
   Axle Covers/Caps  Shop Now
   Truck Hitch/Tow Bar 20,000 Pound Rating (If Equipped)
      Tow Chains 5/8" Grade 70 or OEM Specifications   Shop Now
   Two (2) 48"L x 4"W x 4"D Crossbeams (Minimum)
   Pintle Hook  Shop Now
   Under Lift Rating — 32,000 lbs. Retracted
   Under Lift Rating — 16,000 lbs. Extended
   Under Lift/Fork Adapters w/ Tie-Down Straps or Chains  Shop Now
   Aluminum Tow Angles (Minimum 2)  Shop Now
   Safety Tie-Down Chains and Binders  Shop Now
   Truck Hitch/Tow Bar 20,000 Pound Rating (If Equipped)  Shop Now
   Tow Sling with 20,000 Pound Rating (If Equipped)
