Gunnebo

The Gunnebo-Johnson Anchor Hook allows you to weld onto any surface for an added anchor point. Spring-loaded latch is very strong, made from alloy steel, same as the hook. Welding instructions are supplied. Proof-tested and certified.

J-Latch is a uniquely engineered hood latch system that provides outstanding flexibility and durability. Has a removable 2 position pin that allows the J-Latch to function either as a locked bar or as an automatic spring latch. Will fit a standard 7 ton hook. This part can be used to replace Part Number 174017124.

J-Latch is a uniquely engineered hood latch system that provides outstanding flexibility and durability. Has a removable 2 position pin that allows the J-Latch to function either as a locked bar or as an automatic spring latch. Will fit a standard 15 ton hook. This part can be used to replace Part Number 174017127.

J-Latch is a uniquely engineered hood latch system that provides outstanding flexibility and durability. Has a removable 2 position pin that allows the J-Latch to function either as a locked bar or as an automatic spring latch. Will fit a standard 5 ton hook.

Kuplers act as a connection device between master links and chain legs. Resembling a shackle in appearance, they provide high strength connection. Alloy steel.

This is a replacement latch.

These top of the line grade 80 clevis sling hooks from Gunnebo-Johnson are made from quenched and tempered alloy steel for a very high strength. Low weight, high wear resistance and long life. Sold with or without the heavy duty latches, each hook is supplied with a clevis pin and roll pins to attach it to your chain.

As part of Gunnebo-Johnson's SK system of custom rigging solutions, the 5/16" Closed Pear Master Link stands out as an excellent choice for single leg sling of chain, synthetic or wire rope. The link has been proof tested and certified and has a working load limit of 4,500 lbs.

This Berglok 5/16" clevis and pin from Gunnebo Johnson is primarily used with the LK sliding choker and allows for assembly of chain systems with engineered flats. The clevis fits most Gunnebo eye hooks.

Imperial

Item #	GI-Z101844	GI-Z100845	GI-B14771	GI-B14772	GI-B14773	GI-B14774	Z101152
Code	GG-6-10	GG-7-10	GG-8-10	GG-10-10	GG-13-10	GG-16-10	GG-20-10
WLL lb*	3,306	4,500	5,700	8,800	15,000	22,600	35,300
L	2.13	2.24	2.24	2.99	3.82	3.82	5.79
B	0.31	0.39	0.39	0.47	0.63	0.79	1.02
Weight lb	0.44	0.66	0.88	1.98	3.97	6.83	15.43
Fulfills requirements in: EN 1677:2008 (WLL +25%), ASTM A952/A952M and AS 3776:2015. *Safety factor 4:1. All dimensions in inches.

Metric

Item #	GI-Z101844	GI-Z100845	GI-B14771	GI-B14772	GI-B14773	GI-B14774	Z101152
Code	GG-6-10	GG-7-10	GG-8-10	GG-10-10	GG-13-10	GG-16-10	GG-20-10
WLL tonnes*	1.5	2.0	2.6	4.0	6.8	10.3	16.0
L	54	57	57	76	97	114	147
B	8	10	10	12	16	20	26
Weight kg	0.2	0.3	0.4	0.9	1.8	3.1	7.0
Fulfills requirements in: EN 1677:2008 (WLL +25%), ASTM A952/A952M-02 and AS 3776:2015. *Safety factor 4:1. All dimensions in mm.

These top of the line grade 80 clevis sling hooks from Gunnebo-Johnson are made from quenched and tempered alloy steel for a very high strength. Low weight, high wear resistance and long life. Sold with or without the heavy duty latches, each hook is supplied with a clevis pin and roll pins to attach it to your chain.

The Master Grab Duo MGD master link works with GrabIQ slings from Gunnebo. The all-in-one compact top link allows slings to handle different capacities and the ability to add and and remove legs as needed. Two built-in shortening functions allow the user to switch from a straight lift to a looped sling in a matter of seconds. Choose from five sizes with Working Load Limits ranging from 4,700 lbs. to 39,100 lbs. This master link offers a Safety Factor of 4:1.

Imperial

Item #	GI-Z101114	GI-Z101104	GI-Z101028	GI-Z101036	GI-Z101044	GI-Z101093
Code	BKL-6-10	BKL-7/8-10	BKL-10-10	BKL-13-10	BKL-16-10	BKL-18/20-10
WLL lb*	3,306	5,700	8,800	15,000	22,600	35,300
L	5.87	7.20	8.58	11.10	13.43	14.49
B	1.14	1.46	1.77	2.17	2.44	2.68
C	0.91	1.06	1.46	1.93	2.56	2.76
E	1.30	1.50	1.73	1.89	2.40	2.83
A	0.43	0.47	0.59	0.75	0.98	1.22
G	0.59	0.67	0.83	1.18	1.46	1.73
H	0.83	1.02	1.22	1.57	1.97	2.44
Weight lb	1.54	2.65	4.41	8.82	15.87	25.13
Fulfills requirements in: EN 1677:2008 (WLL +25%), ASTM A952/A952M and AS 3776:2015. *Safety factor 4:1. All dimensions in inches.

Metric

Item #	GI-Z101114	GI-Z101104	GI-Z101028	GI-Z101036	GI-Z101044	GI-Z101093
Code	BKL-6-10	BKL-7/8-10	BKL-10-10	BKL-13-10	BKL-16-10	BKL-18/20-10
WLL tonnes*	1.5	2.6	4.0	6.8	10.3	16.0
L	149	183	218	282	341	368
B	29	37	45	55	62	68
C	23	27	37	49	65	70
E	33	38	44	48	61	72
A	0.43	0.47	0.59	0.75	0.98	1.22
G	0.59	0.67	0.83	1.18	1.46	1.73
H	0.83	1.02	1.22	1.57	1.97	2.44
Weight kg	1.54	2.65	4.41	8.82	15.87	25.13
Fulfills requirements in: EN 1677:2008 (WLL +25%), ASTM A952/A952M-02 and AS 3776:2015. *Safety factor 4:1. All dimensions in mm.

The M Master Link from Gunnebo is used with GrabIQ slings. Choose from 16 sizes with Working Load Limits ranging from 3,306 lbs. to 275,500 lbs. Featuring a Safety Factor of 5:1, each M Master Link can handle up to five separate sling legs with quick insertion and removal as needed for the lifting job.

This GrabiQ G Coupling Link from Gunnebo features a heavy-duty retaining collar for semi-permanent connections for chains, slings and hooks. The coupler is forged with extra-wide inside dimension, and a heat number identification allows for full product traceability. The heavy-duty finish ensures product durability. Featuring a Safety Factor of 4:1, the Grade 100 coupler is approved for overhead lifting and 25 percent stronger than Grade 80. Choose from 10 sizes and Working Load Limits ranging from 3,306 lbs. to 88,160 lbs. Various sizes allow slings to handle different capacities.

The MF Master Link from Gunnebo is used with GrabIQ slings. Choose from 7 sizes with Working Load Limits ranging from 3,306 lbs. to 68,103 lbs. Featuring a Safety Factor of 5:1, each MF Master Link can handle up to four separate sling legs with quick insertion and removal as needed for the lifting job.

Crosby pin latch assembly.

Increase the flexibility in your overhead lifting operations with Gunnebo’s GrabIQ FlexiLeg chain sling kits from Zip’s AW Direct. Add or remove legs as needed for the object being lifted with the removable QuickPin on each connecting hook to the master link. This stainless steel pin allows for safe exchange of sling legs and offers an instant open and close function so no tools are required.

Increase the flexibility in your overhead lifting operations with Gunnebo’s GrabIQ FlexiLeg chain sling kits from Zip’s AW Direct. Add or remove legs as needed for the object being lifted with the removable QuickPin on each connecting hook to the master link. This stainless steel pin allows for safe exchange of sling legs and offers an instant open and close function so no tools are required.

Overcome lifting challenges in construction, manufacturing and assembly with Gunnebo’s GrabIQ single leg chain sling system. GrabIQ kits from Zip’s AW Direct offer quicker, safer and simpler lifting operations with intelligent design and multiple functions in each component. Fewer components mean less weight and less expense than traditional chain slings.

The Master Grab MG master link works with GrabIQ slings from Gunnebo. The all-in-one compact top link allows slings to handle different capacities and the ability to add and and remove legs as needed. The built-in shortening function allows the user to switch from a straight lift to a looped sling in a matter of seconds. Choose from five sizes with Working Load Limits ranging from 3,306 lbs. to 22,600 lbs. This master link offers a Safety Factor of 4:1.

This is a snap ring thumb screw, 8 ton 8".

This eye type sling hook has the same quality features as the clevis type sling hook. High strength, alloy steel, may be used in towing or lifting applications. Use the Gunnebo-Johnson coupling link to attach it to your chain or cable.

Overcome lifting challenges in construction, manufacturing and assembly with Gunnebo’s GrabIQ dual leg chain sling system. GrabIQ kits from Zip’s AW Direct offer quicker, safer and simpler lifting operations with intelligent design and multiple functions in each component. Fewer components mean less weight and less expense than traditional chain slings.

Imperial

Item #	GI-B14460	GI-Z100843	GI-B14461	GI-B14462	GI-B14463	GI-B14464	GI-Z101127
Code	EGKN-6-10	EGKN-7-10	EGKN-8-10	EGKN-10-10	EGKN-13-10	EGKN-16-10	EGKN-20-10
WLL lb*	3,306	4,500	5,700	8,800	15,000	22,600	35,300
L	3.39	3.74	3.74	4.76	5.71	6.69	8.23
B	0.98	1.06	1.10	1.38	1.65	2.09	2.56
G	0.67	0.67	0.67	0.91	1.10	1.42	1.65
H	0.79	0.91	0.91	1.22	1.50	1.81	2.36
Weight lb	0.88	1.10	1.10	2.43	4.85	8.82	16.76

Metric

Item #	GI-B14460	GI-Z100843	GI-B14461	GI-B14462	GI-B14463	GI-B14464	GI-Z101127
Code	EGKN-6-10	EGKN-7-10	EGKN-8-10	EGKN-10-10	EGKN-13-10	EGKN-16-10	EGKN-20-10
WLL tonnes*	3,306	4,500	5,700	8,800	15,000	22,600	35,300
L	3.39	3.74	3.74	4.76	5.71	6.69	8.23
B	0.98	1.06	1.10	1.38	1.65	2.09	2.56
G	0.67	0.67	0.67	0.91	1.10	1.42	1.65
H	0.79	0.91	0.91	1.22	1.50	1.81	2.36
Weight kg	0.88	1.10	1.10	2.43	4.85	8.82	16.76
